Conveyor Parts
Newton Crouch Conveyor parts has been building the best since 1940. Many of our spreaders last for years without replacement parts, but we know that when you need a replacement part, you need them quick. All of our spreaders come standard with stainless conveyor chains. Our combo fertilizer and lime spreaders have 16” or 24” conveyor chains. If you are looking for our fertilizer only spreader with a 8” chain, see our NC series parts. For a complete list of Newton Crouch parts, see our entire Parts Catalog.
Have the Following Information to Ensure Correct Parts are Ordered:
- Serial number
- Width of Conveyor Chain
- Clinched or Straight Bed Chain
- Size of Take Up Bearing
- See Sprocket Assembly Drawing*
Press WHeel Conveyor Parts
- 16″ or 24″ Chain Conveyors with Press Wheel
| Ref | Qty 16” | Qty 24” | Part No. | Description |
|---|---|---|---|---|
| A | 1 | 1 | NC-015049U** | Jack Shaft, 1¼” x 36” |
| A | 1 | 1 | NC-015092AH** | Jack Shaft, 1¼” x 40” |
| A | 1 | 1 | NC-015092AI** | Jack Shaft, 1¼” x 45” |
| C1 – on all spkts | KE-516112 | Key, 5/16” x 1½” | ||
| D1 | 3 | 3 | BR-PB114◊ | PB Bearing, 1¼” on Brackets |
| D1 | 4 | 4 | BR-PB114◊ | PB Bearing, 1¼” on H-Frame |
| D1 | 14 | 14 | BN-SSHH122 | Hex Head Bolt, ½” x 2”, SS |
| D1 | 14 | 14 | BN-SSHN12 | Hex Nut, ½”, SS |
| D1 | 14 | 14 | BN-SSLW12 | Lock Washer, ½”, SS |
| D1 | 14 | 14 | BN-SSFW12 | Flat Washer, ½”, SS |
| D2 | 1 | 1 | NC-015049AZ | H Frame Assy Narrow |
| D2 | 1 | 1 | NC-015049DA | H Frame Assy Universal |
| D2 | 1 | 1 | NC-015054A | H Frame Assy Truck w/ Top Link |
| F | 10’ | 10’ | CA-RC60SS | Roller Chain, SS, 60, Master & Half Link |
| H | 2 | – | BR-PB112◊ | PB Bearing, 1 1/2” on RR Assy |
| H | – | 2 | BR-PB200◊ | PB Bearing, 2” on RR Assy |
| H | 4 | 4 | BN-SSHH122 | Hex Head Bolt, ½” x 2”, SS |
| H | 4 | 4 | BN-SSHN12 | Hex Nut, ½”, SS |
| H | 4 | 4 | BN-SSLW12 | Lock Washer, ½”, SS |
| H | 4 | 4 | BN-SSFW12 | Flat Washer, ½”, SS |
| I or J | See Roller Parts | |||
| K | 2 | 2 | NC-025005Q | Take Up Screw, 5/8” x 12” |
| L | 4 | 4 | BN-SSAHN58 | Nuts, SS, Acme Thread, ⅝” |
| M | 2 | 2 | BR-TU112IMP◊ | Take Up Bearing, 1½” (match FR) |
| M | 2 | 2 | BR-TU100IMP◊ | Take Up Bearing, 1” (match FR) |
| N | 1 | – | CA-CBCW16 | Conveyor Chain, 16” Clinched |
| N | 1 | – | CA-BCW16 | Conveyor Chain, 16” Straight |
| N | – | 1 | CA-CBCW24 | Conveyor Chain, 24” Clinched |
| N | – | 1 | CA-BC24 | Conveyor Chain, 24” Straight |
| N | – | 1 | CA-BCHD24 | Conveyor Chain, HD 24″ Straight,Reinforced |
| – | 1 | – | CA-SP16 | Splice Pin, 16” |
| – | – | 1 | CA-SP24 | Splice Pin, 24” |
| O | 1 | 1 | NC-015104G | Drive Wheel Assy, Single Paddle, Pull Type, 4.8 x 8 |
| O | 1 | 1 | HA-101300 | Bolts for Drive Wheel, Steel Wheel |
| O | 1 | 1 | WT-ASSY5X8X15LAMO | Laminated Tire, Pull Type, 4.8 x 8 |
| O | 5 | 5 | HA-101325 | Bolts for Laminated Air-filled Tire, 1 1/4″ |
| O | 1 | 1 | WT-ASSY480X8B | Air Tire, Rubber Filled, Pull Type, 4.8 x 8 |
| O | 1 | 1 | WT-ASSY205X8X1000 | Air Tire, Truck, 20.5 x 8 |
| P | 1 | 1 | NC-015049AV | Drive Wheel Shaft, 1¼” x 20” |
| P | 1 | 1 | NC-015092AG | Drive Wheel Shaft, 1¼” x 24” |
| P | 1 | 1 | NC-015092BK | Drive Wheel Shaft, 1¼” x 27” |
| Q | 1 | 1 | CN-015049AY | Drive Wheel Hub, 1¼” |
| Q | 1 | 1 | NC-015092BH | Clutch for Drive Wheel, Truck |
Controller Conveyor Parts
- 16″ or 24″ Chain Conveyor with Controller
| Ref | Qty 16” | Qty 24” | Part No. | Description |
|---|---|---|---|---|
| 11 | 1 | 1 | HM-RE10 | Hydraulic Motor, Parker, RE 10 |
| HM-RE10E | Hydraulic Motor, Eaton, RE 10 | |||
| 11 | 1 | 1 | HM-RE14 | Hydraulic Motor, Parker, RE14 |
| HM-RE14E | Hydraulic Motor, Eaton, RE14 | |||
| 11 | 1 | 1 | HM-RE18 | Hydraulic Motor, Parker, RE18 |
| HM-RE18E | Hydraulic Motor, Eaton, RE18 | |||
| 11 | 1 | 1 | HM-RE24 | Hydraulic Motor, Parker, RE24 |
| HM-RE24E | Hydraulic Motor, Eaton, RE24 | |||
| 11B | 1 | – | GB-301095S | Gear Box, 1½” LH, No Sensor |
| 11C | 1 | 1 | GB-301075S | Gear Box, 2” LH, No Sensor |
| 11D◊ | 1 | 1 | GB-301098S | Gear Box, 1½” LH, Sensor ◊ |
| 11E◊ | 1 | 1 | GB-301091S | Gear Box, 2” LH, Sensor ◊ |
| 11F | 1 | 1 | BN-AHSH5161 | Allen Head Screw, 5/16” x 1” (2” Shaft) |
| 23 | 2 | 2 | HH-848FSO1210 | Fitting, Hydraulic, ¾ JIC x ⅝” O Ring |
| 44A | 1 | – | CA-BCW16 | Conveyor Chain, 16″ Straight |
| 44A | 1 | – | CA-CBCW16 | Conveyor Chain, 16″ Clinched |
| 44B | – | 1 | CA-BC24 | Conveyor Chain, 24″ Straight |
| 44B | – | 1 | CA-BCHD24 | Conveyor Chain, HD 24″ Straight, Reinforced |
| 44B | – | 1 | CA-CBCW24 | Conveyor Chain, 24″ Clinched |
| 47A | 2 | 1 | BR-PB112** | Pillow Block Bearing, 1½” |
| 47B | 2 | 2 | BR-PB200** | Pillow Block Bearing 2” |
| 47B | 2 | 2 | BR-PB200HD | Heavy Duty Pillow Block Bearing, 2″ |
| 48 and 49 | See Roller Parts Parts | |||
| 50 | 2 | 2 | NC-025005Q | Take Up Screw, ⅝” x 12” |
| 50A | 2 | 2 | BN-SSAHN58 | Take Up Screw Nut, ⅝” |
| 51A | 2 | 2 | BR-TU112IMP** | Take Up Bearing, 1½” |
| 51B | 2 | 2 | BR-TU100IMP** | Take Up Bearing, 1” |
| 52A | 4 | 4 | BN-SSHH122 | Hex Head Bolt, ½” x 2” |
| 52B | 4 | 4 | BN-SSHN12 | Hex Nut, ½” |
| 52C | 16 | 16 | BN-SSFW12 | Flat Washer, ½” |
| 53A | 1 | 1 | NC-015005DNP | Rear Roller Adapter, 2” LH Slot Sensor |
| 53B | 1 | 1 | NC-015005DVP | Rear Roller Adapter, 1½” LH Slot Sensor |
| 54A | 1 | 1 | RA-0630171443 | Raven Slot Sensor, 25’ Cable, NC Std |
| 54B | 1 | |||
| 1 | 1 | MD-1200009 | Dickey John 360 Slot Senor, 25’ Cable | |
| 1 | MD-1200009A | 360 Slot Sensor Adapter Cable | ||
| 54R◊ | 1 | 1 | MD-1605004KIT | MidTech Rate Senor & Cable |
| Ref No. 54R◊ | ||||
| Kit Includes | MD-4505114 | Sensor Cable | ||
| MD-1605000 | Rate Sensor | |||
| MD-5005007 | MT Rate Sensor U-Cup Seal | |||
| MD-6010000 | Clamp, Loop, 304 SST | |||
| 55A | 1 | 1 | TP-HB038 | Hose Barb, 3/8″ |
| 55B | 1 | 1 | CL-0600 | Clamp, 3/8″ Stainless Steel |
| 55C | 1 | 1 | HO-CT38BPVC | Hose, 3 Feet Needed |
