NC Series Parts
Need a replacement part for your NC Series Fertilizer Only Spreader? NC Series spreader replacement parts are factory made for our NC1500, NC2000, NC3000, NC5000, NC6000, and NC8000. Call our parts department or your local dealer to purchase replacement parts. View our catalog with specification drawings to determine which parts you need. In addition, have your serial number available when calling as it will help our parts team ensure you get the correct parts for your model.
ChutE and Belts
| Ref. No | Qty | Part No. | Description |
|---|---|---|---|
| 1 | 1 1 | NC-025008AM NC-025008BZ | Chute Assembly, Dual Spinners Chute Assembly, Single Spinner Both Assemblies Include: Ref. No 2,3,6,7,8,9 (Pullies Not Included) |
| 2 | 1 | NC-025079H | Upper Bearing Mounting Plate |
| 3A | 2 | NC-015092P | Spinner Shafts |
| 3B | 2 | PP-PVC100 | PVC for Spinner Shaft |
| 3C | 1 | KE-14112 | Key, 1/4″ x 1-1/2″ |
| 4 | 2 | PU-DB965010** | Pulley, Single Groove 6”, 1” Bore 540 RPM or 1000 RPM |
| 5 | 1 | PU-BVI10801** | Idler Pulley, 6 ½” x ⅝” Bore |
| 6 | 1 | NC-025077H | Belt Guide Assembly |
| 6A | 1 | NC-025008CD | Belt Tension Adjustment, 3/8 Rod |
| 7 | 4 | BR-3BF100 | Flange Bearing 1”, 3 Bolt |
| 8 | 1 | NC-025008AA | Chute Material Deflector |
| 9 | 2 | SE-013713593 | Clipper Oil Seal, 1 ⅜” |
| BT-BB122 | Belt for Dual Spinners, 540 | ||
| BT-BB116 | Belt for Dual Spinners, 1000 | ||
| BT-BB111 | Belt for Single Spinners |
ChutE and Belts with Enclosures
| Ref. No | Qty | Part No. | Description |
|---|---|---|---|
| 1 | 1 | NC-025008AMSS | Chute Assembly, Dual Spinners Assembly Includes: Ref. No 2,3,6,7,8,9 (Pullies Not Included) |
| 2 | 1 | NC-025079T | Upper Bearing Mounting Plate |
| 3A | 2 | NC-015092P | Spinner Shafts |
| 3C | 1 | KE-14112 | Key, 1/4″ x 1-1/2″ |
| 4 | 2 | PU-DB96501** | Pulley, Single Groove 6”, 1” Bore 540 RPM or 1000 RPM |
| 5 | 1 | PU-BVI10801** | Idler Pulley, 6 ½” x ⅝” Bore |
| 6 | 1 | NC-025077H | Belt Guide Assembly |
| 6A | 1 | NC-025008CD | Belt Tension Adjustment, 3/8 Rod |
| 7 | 4 | BR-SS3BF100 BR-3BF100 | 3 Bolt Flange Bearing, 1″ SS 3 Bolt Flange Bearing, 1″ |
| 8 | 1 | NC-025008AA | Chute Material Deflector |
| 9 | 2 | NC-025079S | Spinner Shaft Enclosures w/o Bearings |
| BT-BB122 | Belt for Dual Spinners, 540 | ||
| BT-BB116 | Belt for Dual Spinners, 1000 |
Conveyor and Roller Assembly
| Ref. No | Qty | Part No. | Description |
|---|---|---|---|
| 1 | 1 | CN-015005AB | Front Roller, 1” x 12, No Spkt |
| 2 | 1 | CN-015005AC | Rear Roller, 1” x 14½”, 4 Spkt |
| 1 | PM-025005CT | Rear Roller Cover Plate | |
| 3 | CA-BC07 | Bed Chain, 7” x 14’ NC1500, NC2000 | |
| 3 | CA-BC07 | Bed Chain 7”x 16’, NC5000 | |
| 3 | CA-BC07 | Bed Chain, 7”x 20’ NC6000, NC8000 | |
| 3A | CA-SP07 | Splice Pin, 7” | |
| 4 | 2 | KE-516112 | Bearing Stops, 5/16″ x 1 1/2″ |
| 5 | 2 | BR-PB100IMP | Bearing 1”, Pillow Block |
| 6 | 2 | BR-TU100IMP | Bearing 1”, Take Up |
| 7 | 2 | NC-025005Q | Screw, Take Up |
| 8 | 4 | BN-SSAHN58 | Acme Nut, SS, ⅝” |
| 9 | 4 | BN-SSHH38112 | Bolt, 3/8” x 1½/” |
| 10 | 4 | BN-SSLN38 | Lock Nut, ⅜” |
| 11 | 1 | SP-205030X2050400 | Transmission Sprocket, 40 & 30, 1″ Bore |
| 11A | 1 | KE-SK042112 | Key, 5/16″ x 1/4″ |
Drive Shaft
| Ref. No | 540 RPM | 1000 RPM | Part No. | Description |
|---|---|---|---|---|
| 1 | 1 | 1 | NC-015005AD | Front Drive Shaft (NC15000, NC2000, &NC5000) |
| 1 | 1 | 1 | NC-015005AG | Front Drive Shaft (NC6000 & NC8000) |
| 2 | 1 | 1 | NC-015005AE | Rear Drive Shaft (NC1500 & NC2000) |
| 2 | 1 | 1 | NC-015005AF | Rear Drive Shaft (NC5000) |
| 2 | 1 | 1 | NC-015005AH | Rear Drive Shaft (NC6000 & NC 8000) |
| 3 | 1 | – | PU-DB128501 | Pulley Single Groove 8″, 1″ Bore 540RPM |
| 3 | – | 1 | PU-DG412X100 | Pulley Single Groove 4.5″, 1″ Bore 1000RPM |
| 3A | 1 | 1 | KE-14112 | Key, 1/4″ x 1 1/2″ |
| 4 | 3 | 3 | BR-PB100IMP | Pillow Block Bearing, 1″ |
| 5 | 1 | 1 | UJ-393010393 | STD Universal, 1″R x 1″R |
| 5A | 2 | 2 | KE-K15N | Woodruff Key, 1/4″ x 1 |
| 6 | 1 | 1 | NC-025079L | PTO Support Assembly |
| 6 | 1 | 1 | NC-025079Q | PTO Support Assy, Narrow Track |
| 7 | 6 | 6 | BN-SSHH38112 | Bolt 3/8″ x 1 1/2″ |
| 8 | 6 | 6 | BN-SSLN38 | Lock Nut, 3/8″ |
| 9 | 1 | 1 | NC-025079M | PTO Locking Assembly |
| 10 | 1 | 1 | KE-14112 | Key, 1/4″ x 1 1/2″ |
| 1 |
540 PTO Shaft
| Ref. No | Qty | Part No. | Description |
|---|---|---|---|
| – | 1 | GB-TR6QDP38 | PTO Shaft Assembly, 3/8”, 6 Spline |
| – | 1 | GB-TR6QDP38M | PTO Shaft Assy, 3/8”, 6 Spline, Modified |
| – | 1 | GB-9721154 | Outer Guard |
| – | 1 | GB-9621154 | Inner Guard |
| A | 1 | GB-9210600 | Kit, Nylon 6, Easy Lock |
| B | 1 | GB-9002560 | Shield, 250, Plastic, x 60 in |
| C | 1 | GB-0415169 | Bushing, AS250 |
| D | 1 | GB-10000648 | Assy., 6, Yoke, & Shaft x 48 |
| E | 2 | GB-2000600 | Cross and Bearing Kit, 6R |
| F | 1 | GB-1020606 | Yoke, 6, Trac, QD 1 3/8″ x 6 |
